9.5 Cable Assemblies
9.5.1 Inter-unit cable (CFQ6774-10/15/20, CFQ6882-10/15/20)
(a) This cable is used to connect the display unit to the scanner unit.
(b) Use the following cables with connectors for this radar equipment.
Cable length JRC Code for JMA-2343
JRC Code for
JMA-2344
Remarks
15m
10m
20m
CFQ6774-15
CFQ6774-10
CFQ6774-20
CFQ6882-15
CFQ6882-10
CFQ6882-20
Standard/Option
Option
Option/Standard
Color Number of Conduc-
tors/Diameter (mm)
Signal Name
Shielded wire (conductor) : Black 7/0.20 TI
Shielded wire (shield) TIE
Co-axial cable (conductor) 7/0.20 VD
Co-axial cable (shield) VDE
Red (Thick) 50/0.18 1A
Yellow (Thick) 50/0.18 1A
Blue (Thick) 50/0.18 2A
Purple (Thick) 50/0.18 2A
Green (Thick) 50/0.18 1A
Pink (Thick) 50/0.18 1A
Gray (Thick) 50/0.18 2A
Brown (Thick) 50/0.18 2A
Orange (Middle thick) 34/0.18 BP
Green 7/0.20 BZ
Yellow 7/0.20 COM+
White
Twisted pair
7/0.20 COM-
※The outside diameter size of the cable :11.5±0.5 [mm]
Only JMA-2344
