JRC JMA-2343 User Manual

186
Displaying the cursor
Displaying the cursorDisplaying the cursor
Displaying the cursor
(a) Push the soft key ＤＩＳＰＬＡＹ
ＤＩＳＰＬＡＹＤＩＳＰＬＡＹ
ＤＩＳＰＬＡＹ .
(b) Push the soft key 4 and select ＣＵＲ
ＣＵＲＣＵＲ
ＣＵＲ ＯＮ
ＯＮＯＮ
ＯＮ .
Information will be shown as follows at the lower right of the screen.
• When information on speed is input, the maximum travel time displayed is
"9:59".
• The cursor will appear on the PPI screen and the cross key will enter cursor
mode.
Moving the cursor
Moving the cursorMoving the cursor
Moving the cursor
(a) Operating the cross key.
When cursor movement is abandoned, the bearing and distance to that point and
the required travel time to that point are displayed.
Erasing the cursor
Erasing the cursorErasing the cursor
Erasing the cursor
(a) Push the soft key ＤＩＳＰＬＡＹ
ＤＩＳＰＬＡＹＤＩＳＰＬＡＹ
ＤＩＳＰＬＡＹ .
(b) Push the soft key 4 and select ＣＵＲ
ＣＵＲＣＵＲ
ＣＵＲ ＯＦＦ
ＯＦＦＯＦＦ
ＯＦＦ .
The cursor, bearing, distance and required travel time will be erased.
The cross key is in cursor mode.
The cursor function is operating.
Azimuth angle from the bearing of the
ship's bow to the cursor.
Distance from the ship to the cursor.
Travel time when traveling from the
ship's position to the cursor position.
