185
In order to change the method of bearing display on the PPI screen, it is necessary
to input the bearing information from a navigation device.
Please refer to "3.6.1 Obtaining information on bearing" with respect to bearing
display.
Course setting in course
Course setting in courseCourse setting in course
Course setting in course-
--
-up mode
up modeup mode
up mode
(a) Continue to hold down the ＢＲＩＬ／ＨＬ
ＢＲＩＬ／ＨＬＢＲＩＬ／ＨＬ
ＢＲＩＬ／ＨＬ
ＯＦＦ
ＯＦＦＯＦＦ
ＯＦＦ
key.
The course will be set at the top of the PPI screen.
3.3.18 Simultaneously measuring the bearing, distance and travel time to the target
The cursor function is used for this measurement.
The cursor that is used here is indicated by a "+" mark on the PPI screen.
By using this function, in addition to the distance to the cursor, the bearing and travel
time to the cursor position may be obtained.
In order to obtain the travel time, it is necessary to input the ship's speed information
from a navigation device.
Please refer to "3.6.2 Obtaining information on speed".
