176
(b) Push the left or right side of the cross key.
This enables operating the VRM selected in (a).
• When the lower portion of the cross key is pushed, the size of the VRM will be
reduced.
• When the upper portion of the cross key is pushed, the size of the VRM will be
increased.
Erasing the #1VRM and #2VRM
Erasing the #1VRM and #2VRMErasing the #1VRM and #2VRM
Erasing the #1VRM and #2VRM
(a) Push the ＶＲＭ
ＶＲＭＶＲＭ
ＶＲＭ key.
• When both #1VRM and #2VRM are displayed.
Push the VRM key and enclose the value of the #1VRM or #2VRM that is to
remain on the screen with dotted lines.
• When either #1VRM or #2VRM is displayed.
Enclose the displayed #1VRM or #2VRM in dotted lines.
(b) Continue pushing the ＶＲＭ
ＶＲＭＶＲＭ
ＶＲＭ key.
The #1VRM or #2VRM selected in (a) will be erased.
2. Moving the center of the VRM
2. Moving the center of the VRM2. Moving the center of the VRM
2. Moving the center of the VRM
Please refer to "3.3.14 Floating VRM and EBL" for the method of using the
floating EBL.
3. Changing the interval between the pa
3. Changing the interval between the pa3. Changing the interval between the pa
3. Changing the interval between the parallel line cursors
rallel line cursorsrallel line cursors
rallel line cursors
Please refer to "3.3.15 Using the parallel line cursor" for the method of using the
parallel line cursor.
4. Using the cross hair cursor
4. Using the cross hair cursor4. Using the cross hair cursor
4. Using the cross hair cursor
Please refer to "3.3.18 Simultaneously measuring the bearing, distance, and
travel time to the target" for the method of using the cross hair cursor.
