228
8.4 Rectifier Unit (NBA-797)
(1)
Dimensions
・Width 270mm
・Height 430mm
・Depth 175mm
(2) Mounting Wall type, drip proof structure
(3) Mass Approx. 18kg
(4) Input power AC 100/110/115/200/220/230V±15%
50/60Hz, Single phase
(5) Power consumption 200VA
(6) Output DC 26V, 7A
8.5 Unit-to-unit Spacing
Maximum Cable Length Standard Cable Length
Scanner to display 20m 15m(JMA-2343) / 20m(JMA-2344)
Display to rectifier (Note) 2m
(Note) About power cable length between display to rectifier, see "9.5.3 Selecting
a Long Cable"
Install each
equipment
so that the length of the cable between a snanner unit and a
display unit does not exceed 20m. If the regular length is exceeded, it may become
the cause of causing poor adjustment and the defect of a system of operation.
・The standard cables are provided with connectors and plugs.
Attention
