229
9 Installation
This chapter has been written for the service technicians to read in case of installation.
WARNING
Only specialized personnel shall perform installation work.
Installation work performed by personnel other than specialized personnel
may cause breakdown of the equipment, poor performance, fire, severe elec-
tric shock and other property and human damages.
9.1 General
Proper installation of a radar unit is essential for extracting full capability of the unit
reliably and for facilitating troubleshooting and maintenance. Follow the guidelines
given below when installing the radar unit.
(a) Install the scanner unit as high as possible while taking its weight into consideration.
(b) Install the display unit in the wheel house for comfortable observation.
(c) The scanner unit and display unit are connected by 10 to 20 m compound cable with 20
conductors with an internal shield. The maximum permissible cable length is 20 m.
Cables larger than 20 m would deteriorate the radar performance of the radar unit.
