JRC JMA-2343 User Manual

214
5.4 Special Parts
JMA-2343
Model
Number
Name Type
Manufacturer
Location of use JRC Code
V201 Magnetron MSF1421B New JRC Scanner unit 5VMAA00049
A101 Circulator H-6AJRD00001 Toshiba Scanner unit 6AJRD00001
A102 Diode limiter NJS6930 New JRC Scanner unit 5EZAA00024
E301 Front end NJT1028 New JRC Scanner unit 5EZAA00039
JMA-2344
Model
Number
Name Type
Manufacturer
Location of use JRC Code
V201 Magnetron MSF1422B New JRC Scanner unit 5VMAA00068
A101 Circulator H-6AJRD00001 Toshiba Scanner unit 6AJRD00001
A102 Diode limiter NJS6930 New JRC Scanner unit 5EZAA00024
E301 Front end NJT1969 New JRC Scanner unit 5EZAA00037
5.5 Circuit Blocks for Repair
NKE-249
Name Unit/ type of circuit Remarks
Modulator circuit CME-307
Receiver NRG-140
NKE-250
Name Unit/ type of circuit Remarks
Modulator circuit CME-308
Receiver NRG-141
Motor unit CBP-153 With rotating pulse generation circuit
Motor brush BRXP05247 Containing 2
