JRC JMA-2343 - Modifications to be Made to the Inboard Power Supply; Display Unit; Scanner Unit

241
9.4 Modifications to be Made to the Inboard Power Supply

Be sure to use the correctly rated fuse. In the event incorrectly rated fuse is used,
this may cause breakdown in the equipment.
 Make modifications as shown below based on the inboard power supply.
(Fuse for 24V is incorporated upon shipment of the equipment)
1.
1.1.
1. Display unit
Display unit Display unit
Display unit
Fuse rating
F1 F2
Inboard power supply
Rating JRC Code Rating JRC Code
DC12V 6.3A 5ZFAD00336 10A 5ZFAD00539
DC24/32V 3.15A 5ZFAD00227 5A 5ZFAD00364
2. Scanner unit
2. Scanner unit2. Scanner unit
2. Scanner unit
No modifications need to be made with respect to the scanner unit.
Attention
