182
• Magnetic bearing display:
This is the bearing of an EBL or cursor displayed with the north indicated by a
magnetic compass taken as 0 degrees.
(Note): The term "true bearing" and the terms "gyro bearing" or "gyrocompass
bearing" used hereafter shall have the same meaning.
In order to display the true bearing or magnetic bearing, it is necessary to input the
bearing information to the display.
Please refer to "3.6.1 Obtaining information on bearing" with respect to bearing in-
formation.
R: EBL relative bearing display
Relative azimuth angle of #1EBL
Relative azimuth angle of #2EBL
T: EBL true bearing display
True azimuth angle of #1EBL
True azimuth angle of #2EBL
M: EBL magnetic bearing display
Magnetic azimuth angle of #1EBL
Magnetic azimuth angle of #2EBL
