Keysight N1913 - Figure 6-4 Frequency Pop-Up

Using N8480 Series Power Sensors 6
Keysight N1913/1914A User’s Guide 181
Now, set the frequency of the signal you want to measure. The power meter
automatically selects the appropriate calibration factor.
4 Press . On dual channel meters, select the required channel.
5 Use the and keys to highlight the Frequency value field and press
to display the Frequency pop-up. Use the numeric keypad to enter the
required value in the Frequency pop-up window.
Figure 6-4 Frequency pop-up
6 Confirm your choice by pressing or .
7 Press key to close the Channel Setup screen. Proceed to make the
measurement.
8 Connect the power sensor to the signal to be measured. The corrected
measurement result is displayed.
MHz
GHz
