Using N8480 Series Power Sensors 6
Keysight N1913/1914A User’s Guide 185
11 Press to complete the entry.
12 Connect the power sensor to the signal to be measured.
13 The corrected measurement result is displayed.
Figure 6-7 Calibration factor displayed
Example
To make a measurement on channel A with a power sensor which has a reference
calibration factor of 99.8% and a calibration factor of 97.6% at the measurement
frequency.
1 Disconnect the power sensor from any signal source.
2 Press , and the channel softkey.
3 Use the numeric keypad to enter 99.8 in the Ref Cal Factor pop-up window.
4 Press to complete the entry.
5 Press and the channel softkey. The Zeroing pop-up is displayed.
