Keysight N1913 - Adapter Test Procedure

General Power Meter Functions 2
Keysight N1913/1914A User’s Guide 109
Adapter Test Procedure
System Calibration
Table 2-6 Equipment list
Instrument Critical specifications Recommended model Manufacturer
Performance network
analyzer (PNA)
10 MHz to 50 GHz E8362B/C, E8363B/C,
N5225A, or similar
Keysight Technologies
Adapters 2.4 mm (f), Type-N (f) 11903B Keysight Technologies
Adapters 2.4 mm (f), 3.5 mm (m) 11901D Keysight Technologies
Mechanical
calibration kit
Type-N, 50 Ω 85054B Keysight Technologies
Mechanical
calibration kit
3.5 mm, 50 Ω 85052B Keysight Technologies
Mechanical
calibration kit
2.4 mm, 50 Ω 85056A Keysight Technologies
11500E cable assembly,
3.5 mm (m)
to 3.5 mm (m)
3.5 mm (m) to 3.5 mm
(m), DC to 26.5 GHz
11500E Keysight Technologies
Table 2-7 Typical specifications
Frequency S-Parameter 08485-60005 08487-60001
50 MHz
S11 and S22 −58 dB −53 dB
S12 and S21
−0.00665 dB (log mag)
0.999235 dB (lin mag) <0.1%
−0.006908 dB (log mag)
0.999205 dB (lin mag)
<0.1%
