General Power Meter Functions 2
Keysight N1913/1914A User’s Guide 83
12 Press or to setup measurement setting such as measurement
averaging, measurement frequency, offsets, duty cycle and so forth. Refer to
“General Power Meter Functions” on page 55 for the setup procedures.
13 Send *OPC (OPeration Complete) command to meter to set the operation
complete bit in the Standard Event Status register when all pending device
operations are completed.
14 Set the meter to continuous trigger mode by sending INITiate:CONTinuous
ON command to meter.
15 Configure and set the required power sweep range and step on the power
source accordingly.
16 Set the power source trigger input and trigger output, then start sweeping.
17 Poll the status of the power meter by sending *ESR?. *ESR? will return a 1
when buffering is completed. Use FETCh? to retrieve all the buffered
measurement.
Refer to the N1913/1914A EPM Series Power Meters Programming Guide for the
commands usage details.
Example of command set:
BUFF:COUN 100
The power meter can be remotely controlled by LAN, USB and GPIB (IEEE488)
programming interfaces. Refer to N1913/1914A EPM Series Power Meters
Installation Guide for details.
