Kohler KDI 1903 TCR Workshop Manual

275
EN
1.
Fasten oil sump F by tightening capscrews E and strictly
following the order shown in Fig. 11.73 (tightening torque
at 20 Nm ).
2.
Loosen capscrews A and remove housing or plate L ( Fig.
11.72 ).
3.
Fasten oil sump F by tightening capscrews E and strictly
following the order shown in Fig. 11.73 (tightening torque
at 47 Nm ).
Loosen the screw 1 again and tighten it to 47 Nm .
Fig. 11.86
