OPERATION DETAILED CONTROLS AND GAUGES
3-123
Defroster Operation
1. Press fan switch (2) and adjust the air flow. When doing
this, check that temperature setting (a) and air flow (b) are
displayed on monitor (7).
2. Press vent selector switch (4) and set vent display (c) on
the display monitor to the following mode.
q To blow air against the top of the glass, set to mode display
(M1) or (M2) as shown in the diagram on the right.
