SPECIFICATIONS SPECIFICATIONS
5-2
SPECIFICATIONS 5
(*1): Equipped with a hydraulic ladder
For details of the loading specification machine, see “SPECIFICATION (7-19)“.
Item Unit PC2000-8
Operating weight
(including 1 operator, 80 kg)
kg 200,000
Bucket capacity m³ 12.0
Name of engine - Komatsu SAA12V140E-3 diezel engine
Engine power kW / rpm
713 / 1,800 (ISO 9249)
728 / 1,800 (ISO 14396)
A Overall length mm 17,030
B Overall height mm 7,135
C Overall width (*1) mm 7,490
D Track width mm 810
E Height of cab mm 7,030
F Tail swing radius mm 5,980
G Length of track mm 7,445
H Tumbler center distance mm 5,780
Min. ground distance mm 825
Travel speed km/h 2.7
Swing speed rpm 4.8
Ambient temperature working range
for operation and storage
°C From -20° C to + 45°C
