Komatsu PC2000-8 - Working ranges; Max. digging reach; Max. digging depth; Max. dumping height

SPECIFICATIONS SPECIFICATIONS
5-3
NOTICE
For details of the loading specification machine, see “SPECIFICATION (7-19)“.
Working ranges Unit PC2000-8
A Max. digging reach mm 15,780
B Max. digging depth mm 9,235
C Max. digging height mm 13,410
D Max. vertical wall depth mm 2,710
E Max. dumping height mm 8,650
F Max. reach at ground level mm 15,305
