X75HD/X75SD Installation and Operation Manual 97
Chapter 5: Initial Configuration
4. Wait a few moments.
The menu of the selected X75HD/X75SD unit appears along with
all of that unit’s settings.
5. Operate the selected unit as required.
Once a unit is selected for remote control, all front panel features
operate as if you were actually at the front panel of the selected
remote unit. This means that the VFD panel, status indicators, and
buttons (with the exception of the Remote and Option button) all
control and/or reflect the status of the remote unit, not the one you
are physically operating.
6. To switch to another unit, or to control the local device you are
physically operating, click Remote, and then select a new device to
control.
7. Select <local device> to resume normal single-unit operation.
Using a Frame-Mounted Local Control Panel for Remote Operation
After ensuring that all connections and network settings have been
made, you can also remotely control X75HD/X75SD units that are on
the network using a frame-mounted local control panel. To do this, click
Remote on the LCP to enter Remote mode, and to view the list of
X75HD/X75SD units available for control on the same subnet. The
procedure remains the same for selecting and operating devices
remotely via the LCP, as it does for the X75-RCP.
Note
The light on the Remote button
flashes while the unit is
remotely controlling a device.
