124 X75HD/X75SD Installation and Operation Manual
Chapter 6: Operation via Front Panel Controls
Autotrack Status LED
The Autotrack LED indicates whether or not the audio Auto Track
mode is enabled. You can independently set each audio synchronizer to
track the selected output video channel to auto compensate the
propagation delay introduced in the processed video path. Also, you can
add the additional delay with the Audio Delay controls. Follow this
path: Audio Setup>Input Setup>Delay
M-Path Status LED
The M-Path LED indicates whether or not the unit is in M-Path mode.
If the M-Path LED is not lit, the Simulcast mode is in effect.
Simulcast Status LED
The Simulcast LED indicates when the unit is in Simulcast mode. If the
Simulcast LED is not lit, the M-Path mode is in effect.
Table 6-5. Autotrack LED Definitions
LED Status Operating Condition
On Any one of the I/O Delay SRC# parameters in Audio
Setup>Global Audio Config>I/O Delay Config is set to
an option that is other than None.
Off The audio delay feature is turned off.
Table 6-6. Digi-Triplex LED Definitions
LED Status Operating Condition
On The M-Path mode is enabled (one or more input signals
are selected and routed to the outputs).
Off The M-Path mode is not enabled.
Table 6-7. Simulcast LED Definitions
LED Status Operating Condition
On The Simulcast mode is enabled.
Off The Simulcast mode is not enabled.
