X75HD/X75SD Installation and Operation Manual 165
Chapter 10: Special Function Buttons
Using the Freeze Control
The freeze control freezes individual frames or fields of the incoming
video source. The Freeze mode only affects the currently active video
proc amp block.
To use the freeze shortcut, follow these steps:
1. Press Frz Mode to open a menu in the VFD panel where you can
select a mode to apply to the incoming video.
2. Press Frz Mode multiple times to cycle through the different
modes.
Available modes include the following:
• Field 1
• Field 2
•Frame
3. Press Take to activate the selected Freeze mode and apply it to the
incoming video.
The Take button flashes while the Freeze mode is active.
4. Press the Take button repeatedly to toggle between live and freeze
modes.
Note
The Mute In Freeze option
(Audio menu) specifies whether
or not audio output will be
muted while the video is frozen
in Frame or Field mode.
