4 X75HD/X75SD Installation and Operation Manual
Chapter 1: Introduction
General Description
Offering unparalleled flexibility, the X75HD/X75SD provides up to
nine video inputs and ten video output formats, depending upon the
following available options:
• One HDTV optical fiber serial component digital video input and
output
• Two HDTV serial component inputs (one can be selected as optical
fiber) and one HDTV output (two coaxial and one fiber)
• Two SD-SDI serial component digital video inputs and outputs
• One 128 x 96 thumbnail streaming source and one 352 x 240 pixel
(525) or 352 x 288 pixel (625) streaming-over-IP video/audio
output
• Component analog video (Betacam
TM
) input and output
• S-video (S-VHS/Hi8) input and output
• NTSC/PAL-M/PAL-B/SECAM composite video input and output
•RGB-S output
• DVI-D output
See page 35 for descriptions of some typical applications using these
options.
Inputs
Inputs are capable of auto-detection, with user-selectable SMART
alarms. Two input modes (both of which allow for either automatic
detection or user-selection of inputs) are available for processing
critical program paths for ingest, and bridging between routers/tape
transports/servers, mobile broadcast, and edit suites.
Video Processing
Processing for video includes level/color control, aspect ratio
conversion, 3D-adaptive color decoding, noise reduction, frame
synchronization and time base correction for non-synchronous signals,
analog-to-digital and digital-to-analog video conversion.
Other capabilities include the following:
• Up and down conversion
• Aspect ratio control
• High-definition cross-conversion
Note
See “Product Packages” on
page 12 for more specific
information on what each
X75HD/X75SD system package
provides.
