344 X75HD/X75SD Installation and Operation Manual
Appendix F: Specifications
Communication Specifications
Table F-21. Thumbnail Streaming Specifications
Item Specification
Connector RJ-45
Protocols
• CCS
•SNMP
•HTTP
Table F-22. V2A Specifications
Item Specification
Measurement window
± 1.2 seconds between video and audio
Time to provide measurement 5 seconds
Measurement resolution ±2 video lines
Note
The measurement result has
1.64 - 1.66ms delay for HD de-
embedded audio and 1.28 -
1.3ms for SD de-embedded
audio.
Table F-23. RS-232/RS-422 Specifications
Item Specification
Standard Electrical specification EIA-232C
Connector
•DB-9
• 232/422 switchable
• 422 termination can be selected from
the menu
