118 X75HD/X75SD Installation and Operation Manual
Chapter 6: Operation via Front Panel Controls
Using Multi-Function Buttons
Many of the buttons on the X75HD/X75SD control panel are
multi-functional, and can have up to three functions assigned to them.
To select a certain function from a multi-function button, perform one
of the following steps:
• Press the desired multi-function button. The assigned default
function is written in black text on the button face, either near the
top or in the middle of the button.
• Press Shift and the desired multi-function button simultaneously.
The assigned function is written in red text on the button face near
the top of the button.
• Press Ctrl and the desired multi-function button simultaneously.
The assigned function is written in blue text on the button face near
the bottom of the button.
For more information on front panel buttons, see the Control Panels for
X75 Systems Installation and Operation Manual.
Navigating Through the Menus
There are eight main menu items available. Each of them open up into
several layers of submenus and parameter options that you can scroll
through and edit as required. Table 6-1 briefly describes each of the
eight main menu items.
Table 6-1. Main Menu Items
Menu Name Menu Description
Video Setup Configures and controls the video settings
Audio Setup Configures and controls the unit’s audio settings
Reference Setup Configures and controls the genlock and other
reference settings
System Config Configures settings of the initial setup parameters
Global Frame Rate Sets the unit’s frame rate per second
SD Operating Standard Provides a read-only view of the selected or
detected SD-SDI operating standard
HD Output Standard Provides a read-only view of the selected HD-SDI
operating standard
