X75HD/X75SD Installation and Operation Manual 137
Chapter 7: Web Server Software Control
Navigating Menus and Options via
the Menu Navigation Tree
Click Menu Navigation Tree from the Home page to present the
X75HD/X75SD menu structure for selecting and setting options. These
menus mirror the menus that are accessible through the local and
remote control panels of the unit.
The menu listings display available menus and submenus. Click any of
these to open the corresponding configuration page. Figure 7-7 shows a
sample of the Menu Navigation Tree page and a resulting
configuration page that opens when you click a submenu.
Figure 7-7. Menu Navigation Tree Control Page
Menu tree
Click any menu or submenu item to open the
corresponding configuration page.
Clipping submenu configuration page
Click a parameter name from the Clipping
submenu table to set the value; see “Setting a
Selected Value” on page 134 for details.
