144 X75HD/X75SD Installation and Operation Manual
Chapter 8: Video Configuration
Selecting a Video Source
General Information
With control panel video shortcuts, you can select an input (or multiple
inputs) and immediately send it to all video outputs by pressing the
Video In button. The LEDs on the left side of this button indicate which
input is currently selected. The M-Path (multiple inputs) selection
allows any output group to be assigned with the video input sources.
When two or more video sources are selected and mapped to multiple
output groups, the M-Path and corresponding video input source LEDs
will be lit. When the selected input signal is absent, the LED flashes.
Available inputs include the following:
•M-Path
• Composite
•S-Video
•CAV
•SD 1
•SD 2
• DV (future use)
• HD Fiber
• HD 1
• HD 2
If the Auto Detect feature is enabled when a selected input option is not
installed or detected, the panel accepts the next available input. If the
selected video signal is absent, the corresponding video input LED
flashes.
Note
If you have not installed the
appropriate modules, the
corresponding sources are not
available for selection.
