X75SD/X75HD Installation and Operation Manual 27
Chapter 1: Introduction
X75OPT-HDDUOCON Option
An X75 provides up, down, or crossconversion. With the addition of the
HDDUOCON option, simultaneous up and down, or cross and down
conversions are possible.
By selecting the M-Path mode, you can quickly route a particular input
source to all of the X75’s outputs simultaneously. To do this, use the All
Out Select parameter. Follow this path: Video Setup>Routing
Setup>All Out Sel.
Several examples of M-Path video processing are illustrated in
Figure 1-6 on page 28 and Figure 1-7 on page 29.
When you need a single input video source to be processed and sent to
all outputs, press the Video In button or select the Video
Setup>Routing Setup>All Out Sel parameter to select the desired
input video source to be processed. The X75HD/X75SD automatically
routes the selected input to all outputs and inserts any selected
processing blocks.
When multiple and independent video channel processing is required,
the Video M-Path parameter in Video Setup>Routing Setup menu
allows each video output group to be assigned an input source.
Press the Audio In button or select the Audio Setup>Routing>Audio
In Src Select parameter to select a single audio group type to be
synchronized, processed and sent to all outputs. Depending on the
selected input audio group type, the software automatically handles all
internal processing, including de-multiplexing, signal routing,
synchronization, and re-embedding.
The available input audio group types for selection are the following:
• User—When more than one audio input group types is selected
• Analog—Selects all four analog audio inputs for processing
• AES—Selects all AES inputs for processing
Table 1-3. “DUOCON” Conversion Capability
Conversion
With
X75OPT-HDDUOCON
Without
X75OPT-HDDUOCON
Upconversion and downconversion Yes No
Upconversion and crossconversion No No
Downconversion and crossconversion Yes No
Note
If you have routed a particular
input feed to an output, (or
series of outputs) for up, down,
or cross-converting, and then
begin setting up a new
conversion pattern, the existing
conversion will be disrupted
immediately.
Note
Analog component video inputs
are only available if your
X75HD/X75SD system
includes an X75OPT-PQM or
X75OPT-A3D module.
