X75HD/X75SD Installation and Operation Manual 341
Appendix F: Specifications
Output
Table F-16. Analog Audio Input Specifications
Item Specification
Connector Removable barrier strip
Input impedance Jumper selectable with J5~J8
• Pin 2-3: 100 kΩ
• Pin 1-2: 600 Ω
Input analog level 28 dBu to 16 dBu (adjustable by 2 dB
increments)
CMRR >80 dB @ 60 Hz, typical
Linearity <±0.5 dB (to -100 dBFS)
Frequency response <±0.05 dB (20 Hz to 20 kHz), typical
THD >100 dB (@ -1 dBFS, 20 Hz to 20 KHz)
SNR >100 dB
Table F-17. AES Output Specifications
Item Specification
Balanced
Standard AES3
Type Balanced, transformer coupled
Connector 2 female DB-26/DB-44 connector with
breakout cable
Signal level 4.0 V (pk-to-pk)
Impedance 110Ω ± 20% (0.1 MHz to 6 MHz)
Jitter <± 4 ns, peak value
DC offset 0.0 ± 50 mV
Rise/fall time 5 ns to 30 ns (10% to 90%)
Unbalanced
Standard AES3, SMPTE276M
Type Unbalanced, AC coupled
