342 X75HD/X75SD Installation and Operation Manual
Appendix F: Specifications
Connector BNC (IEC169-8)
Signal level 1.0 V ± 10% (pk-to-pk)
Impedance 75Ω
Return loss >25 dB, 0.1 MHz to 6 MHz
Jitter <± 4 ns, peak value
DC offset 0.0 ± 50 mV
Rise/fall time 30 ns to 44 ns (10% to 90%)
Table F-18. Analog Audio Output Specifications
Item Specification
Connector Removable barrier strip
Output impedance Jumper selectable with J1~J4, J9~J12
• Pin 2-3: 66Ω
• Pin 1-2: 600Ω
Output analog level 28 dBu to 16 dBu (adjustable by 2 dB
increments)
Linearity <±0.5 dB (to -100 dBFS)
Frequency response <±0.1dB (20 Hz to 20 kHz)
THD <-87dB typical (@ -1 dBFS, 20 Hz to 20
KHz)
SNR >100 dB
Table F-17. AES Output Specifications (Continued)
Item Specification
