X75HD/X75SD Installation and Operation Manual 125
Chapter 6: Operation via Front Panel Controls
Major and Minor Alarm LEDs
The Major and Minor Alarm LEDs are activated from the enabled list
of alarms found in the selected frame’s parameters. Local and remote
control panels only detect alarms that are activated on X75HD/X75SD
models that are currently being accessed.
Major alarms appear as red LEDs; minor alarms are amber. See
page 323 for a detailed list of all possible alarms.
Mem Active LED
This LED indicates there is activity on the SD card.
Table 6-8. Major and Minor Alarm LEDs
LED Status Operating Condition
On Alarms are detected.
Off No alarms are detected.
