Appendix F: Specifications
Video Path
When a block is inserted, the FS phase or SD-ARC will be compensated to
maintain output, and the H/V phases won't change. If the SDNR is inserted,
the propagation delay may not change or may add one extra I-frame,
depending upon the FS phasing. The total FS+SDNR delay will be less than
1.5 I-frames.
If the SD-ARC is inserted, the propagation delay will add an extra 0.5 to 1.5
I-frames, depending upon FS phases and SD-ARC/HD-Dn phase settings.
If the strobe is inserted, the propagation delay most likely will not change; if a
delay-line is inserted, the propagation delay will add an extra 0 to 4 I-frames,
depending upon the delay line settings.
If a keyer is inserted, the propagation delay most likely will not change.
Table F-29. Propagation Delay For 1080i/50, 1080p/25, and 720p/50
Input
Decod-
ing
Frame
Sync
HD User
Video
Delay
Up/Dn/Cross SD NR
SD User
Video
Delay
1080i/50 N/A 0~1 I-frame 0~7 I-frames Dn: 1 I-field to 3 I-fields. By default 1 I-frame 1 line ~ 1 I-field 0 ~ 4 I-frames
1080i/50 N/A 0~1 I-frame 0~7 I-frames Dn: 1 I-field to 3 I-fields. By default 1 I-frame 1 line ~ 1 I-field 0 ~ 4 I-frames
1080i/50 N/A 0~1 I-frame 0~7 I-frames 1 I-field to 3 I-fields. By default 1 I-frame N/A N/A
1080i/50 N/A 0~1 I-frame 0~7 I-frames Cross: 1 I-field to 3 I-fields. By default 1 I-frame N/A N/A
1080i/50 N/A 0~1 I-frame 0~7 I-frames Cross: 1 I-field to 3 I-fields. By default 1 I-frame N/A N/A
1080p/25 N/A 0~1 P-frame 0~7 P-frames Dn: 0.5 P-frame to 1 P-frame. By default 1 P-frame 1 line ~ 1 I-field 0 ~ 4 I-frames
1080p/25 N/A 0~1 P-frame 0~7 P-frames Dn: 0.5 P-frame to 1 P-frame. By default 1 P-frame 1 line ~ 1 I-field 0 ~ 4 I-frames
1080p/25 N/A 0~1 P-frame 0~7 P-frames Cross: 0.5 P-frame to 1 P-frame. By default 1 P-frame N/A N/A
1080p/25 N/A 0~1 P-frame 0~7 P-frames 0.8 P-frame to 1.8 P-frame. By default 1 P-frame N/A N/A
1080p/25 N/A 0~1 P-frame 0~7 P-frames Cross: 0.5 1080P-frame to 1 1080P-frame. By default:
1 P-frame
N/A N/A
720p/50 N/A 0~1 P-frame 0~15 P-frames Dn: several lines to 2 P-frames. By default 1 P-frame 1 line ~ 1 I-field 0 ~ 4 I-frames
720p/50 N/A 0~1 P-frame 0~15 P-frames Dn: several lines to 2 P-frames. By default 1 P-frame 1 line ~ 1 I-field 0 ~ 4 I-frames
720p/50 N/A 0~1 P-frame 0~15 P-frames Cross: several lines to 2 P-frames. By default 1
P-frame
N/A N/A
720p/50 N/A 0~1 P-frame 0~15 P-frames Cross: several lines to 3 720P-frames. By default 2
720P-frame
N/A N/A
720p/50 N/A 0~1 P-frame 0~15 P-frames several lines to 1 P-frame. By default 1 P-frame N/A N/A
