322 X75HD/X75SD Installation and Operation Manual
Appendix E: Alarms
Configure Alarms Options
Table E-1 lists the options available in the Configure Alarms menu
and their meanings. To reach the individual alarms, press the Option
button, and then select Configure Alarms.
Table E-1. Configure Alarms Menu
Menu Item Description
Trigger Time A filter that sets the duration (in seconds) between the time an alarm is detected, and the
time an alarm is reported to the Web Server, CCS application, or Alarms LED
Clear Time A filter that sets the length of time the alarm continues to be reported after the alarm
condition is no longer detected (default values are set at 0 seconds)
Priority The numerical value given to the priority of the alarm
(1 = low priority and 10 = high priority; any alarm above 5 is designated Major)
Alarms Disabled An option that silences the alarm, even though the alarm condition may continue to exist
(If the alarm is re-enabled and the condition is not corrected, the alarm is reactivated
immediately.)
Alarm Mute An option that suppresses alarm messages when the state of the alarm changes (The
control panel is affected when the mute is enabled. However, the Web Server application
will display the alarm message in its next polling cycle, or when the user refreshes the
screen. The Alarm Mute is not displayed in CCS applications.)
Acknowledged A “flag” that indicates someone is attempting to correct the source of the alarm
(In X75 control panels, an asterisk appears beside the alarm in the Active Alarms List.)
