340 X75HD/X75SD Installation and Operation Manual
Appendix F: Specifications
Audio Specifications
Input
Table F-15. AES/DARS Input Specifications
Item Specification
Balanced
Standard AES3
Type Balanced, transformer coupled
Connector 2 female DB-26/DB-44 connector with
breakout cable
Sensitivity <200 mV
Impedance 110Ω ± 20% (0.1 MHz to 6 MHz)
Common mode rejection 0 V to 7 V (0 kHz to 20 kHz)
Input audio rate 32 kHz to 108 kHz
Unbalanced
Standard AES3, SMPTE276M
Type Unbalanced, AC coupled
Connector BNC (IEC169-8)
Sensitivity <100 mV
Impedance 75Ω
Return loss >25 dB, 0.1MHz to 6 MHz
Input audio rate 32 kHz to 108 kHz
