X75HD/X75SD Installation and Operation Manual 339
Appendix F: Specifications
Table F-14. DVI Output Specifications
Item Specification
Standard
• 1080i/59.94
• 1080i/50
• 720p/59.94
• 720p/50
Connector DVI-D
Rise/fall times 75 ps to 0.4 UI (20% to 80%)
Level 1.0 V ± 0.2 V (differential, pk-to-pk)
Jitter 0.25 UI
