338 X75HD/X75SD Installation and Operation Manual
Appendix F: Specifications
Table F-12. Component Output Specifications
Item Specification
Format Betacam
Connector BNC (IEC169-8)
Quantization
• Y: 12 bits
• Cb: 10 bits
• Cr: 10 bits
Impedance 75Ω
Return loss >40 dB (1 kHz to 6 MHz)
Frequency response
• Y: ±0.1 dB to 5.5 MHz
• Pb/Pr: ±0.10 dB to 3.0 MHz
DC offset <0.0 ± 5 mV
Relative delay <±10 ns
SNR >63 dB
Table F-13. Streaming Output Specifications
Item Specification
Video compression type MPEG4
Profile Simple Profile
Modes Fixed Bit Rate Mode, VBR (Variable Bit
Rate) Mode
Bit rate range control User-settable 200 Kb/s - 1 Mb/s
Frame rate (VBR) 30 fps / 25 fps
Frame rate (fixed) As bit rate is lowered, frame rate is
lowered
Audio compression type AAC (Advanced Audio Coding) format
Profile LC (Low Complexity)
Sample rate 48 K
Stereo bit rate (two channels) 64 Kbps
