Appendix F: Specifications
Table F-10. SD-SDI Video Output Specifications
Item Specification
Standard SMPTE259M-C, 270 Mbps, 525/625
component
Quantization 10 bits
Connector BNC (IEC169-8)
Impedance 75Ω
Return loss >18 dB from 5 MHz to 270 MHz
Signal level 800 mV ± 10%
DC offset 0.0 ± 0.5 V
Rise/fall time 400 ps to 1500 ps (20% to 80%)
Overshoot <10%
Jitter <0.2 UI (pk-to-pk)
Table F-11. Composite Video Output Specifications
Item Specification
Standard
•NTSC
•PAL-B
•PAL-M
Connector BNC (IEC169-8)
Quantization 12 bits
Impedance 75Ω
Return loss >40 dB (0.1 MHz to 6 MHz)
Frequency response ±0.1 dB (0.1 MHz to 6 MHz)
DC offset <0.0 ± 0.005 V
Differential gain <0.5%
Differential phase <0.5°
Y/C delay <10 ns
Transient response <0.5% K Factor
SNR >63 dB (0.1 MHz to 6 MHz)
