X75HD/X75SD Installation and Operation Manual 171
Chapter 10: Special Function Buttons
Audio Proc Amp Status LEDs
The four Audio Proc LEDs (Analog, Digital, SD-SDI, HD-SDI) on the
far right side of the front panel indicate the selected audio input group
that is being adjusted for the audio gain.
• Analog: Lit during analog audio channels gain adjustments
• Digital: Lit for AES and future-use DV channel audio gain
adjustments
• SD-SDI: Lit during SD1 or SD2 (SD-SDI demuxed) channel audio
gain adjustments
• HD-SDI: Lit during HD1 or HD2 (HD-SDI demuxed) channel
audio gain adjustments.
Lit Audio Input
LEDs
This identifies the audio input LED that lights when an
input source is selected.
Find these LEDs above, and to the right, of the Audio
In/A Proc button on a control panel.
Options include Analog, AES, SD-SDI, HD-SDI, and
AFV (Audio Follow Video).
Mapped
Parameters
This identifies
the selected audio input channel’s gain
controls/parameters that are now enabled and available
once a certain audio input source is selected.
Items Applied/Enabled when you Press the “Ctrl” + “A Proc” Buttons
Mapped Buttons
on Control Panel
This identifies the audio proc amp buttons on the right
side of the control panel (labelled 1 through 16) that
become mapped to/correspond with the selected audio
input channel’s gain controls.
Mapped buttons are backlit; unmapped buttons remain
dimmed. Once mapped, press a numbered button to
enable the gain controls assigned to it.
Lit Audio Proc
LEDs
This identifies the audio proc LED that lights when an
audio input source type is selected.
Find these four LEDs on the far right side of the control
panel. Options include Analog, Digital, SD-SDI, and
HD-SDI.
Table 10-7. Table Definitions (Continued)
Item Description
