Appendix A: Cables and Pinouts
Table A-6 describes each pin on the CAB-X75HD-COAX DB-44M
connector and its connection type.
Table A-6. CAB-X75HD-COAX Pinout Description
Pin Number Connection Type Description
1 through 30 NC N/A
31 BNC Unbalanced AES5 out
32 BNC-Gnd Unbalanced AES5 out
Ground
33 BNC Unbalanced AES4 out
34 BNC-Gnd Unbalanced AES4 out
ground
35 BNC-Gnd Unbalanced AES3 out
ground
36 BNC Unbalanced AES3 out
37 NC N/A
38 NC N/A
39 BNC Unbalanced AES5 in
40 BNC-Gnd Unbalanced AES5 in
ground
41 BNC Unbalanced AES4 in
42 BNC-Gnd Unbalanced AES4 in
ground
43 BNC-Gnd Unbalanced AES3 in
ground
44 BNC Unbalanced AES3 in
