X75HD/X75SD Installation and Operation Manual 215
Appendix A: Cables and Pinouts
27 XLR-1-Gnd Balanced AES4 in ground
28 XLR-3 Balanced
AES4 in (-)
29 NC N/A
30 XLR-1-Gnd Balanced AES3 in ground
31 BNC Unbalanced AES5 out
32 BNC-Gnd Unbalanced AES5 out
ground
33 BNC Unbalanced AES4 out
34 BNC-Gnd Unbalanced AES4 out
ground
35 BNC-Gnd Unbalanced AES3 out
ground
36 BNC Unbalanced AES3 out
37 NC N/A
38 NC N/A
39 BNC Unbalanced AES5 in
40 BNC-Gnd Unbalanced AES5 in
ground
41 BNC Unbalanced AES4 in
42 BNC-Gnd Unbalanced AES4 in
ground
43 BNC-Gnd Unbalanced AES3 in
ground
44 BNC Unbalanced AES3 in
Table A-8. CAB-X75HD-COMBO Pinout Description (Continued)
Pin Number Connection Type Description
To Next Page
