X75HD/X75SD Installation and Operation Manual 217
Appendix A: Cables and Pinouts
4 XLR-2 Balanced AES2 in (+)
5 XLR-3 Balanced AES2 in (-)
6 XLR-2 Balanced AES1 out (+)
7 XLR-3 Balanced AES1 out (-)
8NC N/A
9NC N/A
10 NC N/A
11 XLR-1-GND Balanced DARS in ground
12 XLR-1-GND Balanced AES1 in ground
13 NC N/A
14 XLR-1-GND Balanced AES2 in ground
15 NC N/A
16 XLR-1-GND Balanced AES1 out ground
17 XLR-1-GND Balanced AES2 out ground
18 NC N/A
19 NC N/A
20 XLR-3 Balanced AES1 in (-)
21 XLR-2 Balanced AES1 in (+)
22 NC N/A
23 NC N/A
24 NC N/A
25 XLR-3 Balanced AES2 out (-)
26 XLR-2 Balanced AES2 out (+)
Table A-9. X75OPTCAB-8-X Pinout Description (Continued)
Pin Number Connection Type Description
To Next Page
