Actuate the tractor brake pedal*.
(The spring mechanism on the brake cylin-
der is pretensioned and the parking brake
is released)
For driving on roads:
Release the parking brake.
Attach break away cable (6) to a stable
location on the tractor. (Break-away
force 6 daN – equivalent to 60 kg)
If the implement breaks away from the
tractor, the break away cable (6) opens the
brake valve (5). The pretensioned com-
pression springs (4) ensure emergency
brake application.
* The brake pedal on the tractor must be depressed forcefully for
a short period. A quick tap is not enough.
