Software Version 3.05
C-1
APPENDIX C:
Hand Held Remote
This appendix outlines how the Hand Held Remote (HHR) communicates with an
Encore console. This appendix also describes the operation of the HHR within the
Encore operating software.
The optional Hand Held Remote is a very useful device. It unchains you from the
console and allows you to stand on stage and call up and check lights on the move,
making for quick setup and focus. With the HHR, you can access dimmers directly,
regardless of the patch, and move through dimmer or channel checks quickly and
effortlessly. The four-line backlit LCD display allows you to verify your keystrokes,
even in dark locations. For more information about the HHR, or to order an HHR for
your Encore console, please contact:
?? Colortran Customer Service at (800) 959 7999.
Protocol
The Encore Hand Held Remote connector port conforms to the following
protocol:
?? EIA RS-422 standard
?? Baud Rate: 9600
?? Parity: Even
?? Data Bits: 7
?? Stop Bits: 1
?? Does not support Xon/Xoff
Pinout Information
The following chart shows the functions of the pins on the 6-pin Neutrik XLR-
type connector on the console (female connector) and the HHR (male):
