Leviton MC24/48 - Appendix F; Encore Console Specifications

Software Version 3.05
F-1
APPENDIX F:
Encore Console
Specifications
24/48 24/48
Expanded
48/96 48/96
Expanded
XL XL/2
Channels
Two-Scene mode 24 24 48 48 N/A N/A
Multi-Scene mode 144 512 144 512 512 1024
Dimmers
512 512 512 512 512 1024
Submasters
24 24 48 48 48 48
Total Cues/Groups
(per show)
300 550 350 600 600 600
Groups
200 200 200 200 200 200
Effects
(per show)
99 99 99 99 99 99
Size and Weight
Height, inches (cm) 6 (15) 6 (15) 8 (20) 8 (20) 6 (15) 6 (15)
Width, inches (cm) 46 (117) 46 (117) 46 (117) 46 (117) 46 (117) 46 (117)
Depth, inches (cm) 14 (36) 14 (36) 28 (72) 28 (72) 14 (36) 14 (36)
Weight, lbs (kg) 47 (21) 47 (21) 80 (37) 80 (37) 47 (21) 47 (21)
Table F-1 Encore Capacities and Physical Specifications
Interfaces Connector
?? Parallel printer port 25 pin D
?? Dimmer signal for dimmers 1-512 (standard) 5-pin XLR (Neutrik
®
)
?? Dimmer signal for dimmers 513-1024 (XL/2 only) 5-pin XLR (Neutrik
®
)
?? MIDI 5-pin DIN
?? Single video monitor (standard) high density 15-pin D
?? Second (Dual) video monitor (optional) high density 15-pin D
?? Hand Held Remote (optional) 6-pin XLR (Neutrik
®
)
?? Worklights (optional) 3-pin XLR (Neutrik
®
)
