Chapter 3: Displays
Software Version 3.05
59
Playback Cue Rows Number of rows of cue information shown in the Playback display.
Number of channels Total channels configured in your show.
Number of dimmers Total dimmers configured in your show.
Number of submasters Total submasters in your Encore model.
Number of macros Total macros in your Encore model.
Show Name The name of the show currently loaded in the console.
File Name The file name of the show currently loaded in the console.
(This is the file name used on the floppy disk.)
Dimmer Protocol Protocol selected (DMX-512 or CMX).
Sub Level Window EXPANDED or COMPRESSED sub window in Playback display.
Fader Clear Mode AUTOMATIC or MANUAL
MIDI Control Device # or OFF
Reference by Name ON or OFF
Hand Held Remote ON or OFF
Table 3.1, Setup Display Information Fields
Display Formatting Options: Display formatting options are
changes to the display appearance that you can configure. The display
formatting options are:
?? Number of cue rows shown (See Playback Display topic in this
chapter.)
?? Text size (See Text Size topic, below.)
?? Submaster Fader Window size (See Playback Display topic in this
chapter.)
?? Channel formatting (See Basic Display topic, at the
beginning of this chapter.)
Text Size: Pressing the (TEXT SIZE) soft key toggles between the two
different display modes: 27 lines per page, and 43 lines per page. The (TEXT
SIZE) soft key is available under the Display Setup (DISP. SETUP) soft key.
?
HINT: The Compressed text size mode is useful when you need a lot
of information on the screen.
Submaster Fader Window: The Submaster Fader Window in the
Playback display can be toggled between Expanded mode and Compressed
mode by pressing the Submaster Window (SUB WNDOW) soft key, available
under the Display Setup (DISP. SETUP) soft key. The Expanded mode shows
