Colortran Encore Control Console
Software Version 3.05
68
may be to an automated device such as a color scroller or a moving fixture. A
control channel may be patched to a single dimmer or multiple dimmers.
When a dimmer is currently patched to a channel and then re-patched to a new
channel, the dimmer is "robbed" from the previous assignment. The previous
channel assignment is deleted without warning and the dimmer is given to the
new channel assignment.
?
BASIC RULE: Remember that a dimmer can be controlled by only
one channel, but a channel can control any number of dimmers.
Patch Displays
The Patch display consists of two windows of four columns each: Channel,
Dimmer, Level, and Profile. Level refers to a proportional level assigned to an
individual dimmer. Profile refers to a dimmer output curve assigned to an
individual dimmer. The Patch display has two different display modes for the
patch information: the Patch: By Channel display, and the Patch: By Dimmer
display.
Press the (BY CHANL) soft key to access the Patch: By Channel display. Press
the (BY DIM) soft key to access the Patch: By Dimmer display.
?
HINT: The same soft key, S1, toggles between the Patch: By
Channel and the Patch: By Dimmer displays.
