Colortran Encore Control Console
Software Version 3.05
C-2
Belden 9830 Cable
Pairs
Function at Console XLR Pin Number Function at HHR
1st Pair Ground 1 Ground
+12 VDC out 2 +12 VDC in
2nd Pair - Receive Data 3 -Transmit Data
+ Receive Data 4 + Transmit Data
3rd Pair - Transmit Data 5 -Receive Data
+ Transmit Data 6 + Receive Data
Figure C-1 Pin-out Chart for Hand Held Remote
The maximum cable length that the Encore can support for a HHR is 1000 feet,
including all connecting cables and permanent wiring (does not apply to the
wireless version).
Functions
When the Encore console receives a character signal through its Hand Held
Remote port, the console immediately goes to the Stage display and interprets
the character signal as if the corresponding key was pressed on the console.
?
BASIC RULE: The HHR only works live, so the console always
changes to the Stage display when you use the HHR, unless the console is in
the Playback display.
? NOTE: The Go and Stop/Reverse commands do not force the console
into the Stage display.
All commands from the HHR appear in the Encore Command Line, after
"(HHR Remote):", an indicator that lets you know that this command is
originating from the HHR.
? EXAMPLE: To enable and disable the HHR in the Setup display:
1. [SYSTM SETUP] (Reveals the System Setup soft
keys.)
2. [HAND-HELD] (Hand Held Remote toggles ON or
OFF.)
