Colortran Encore Control Console
Software Version 3.05
E-2
?? An Encore console with the ColorNet Remote Video Support Option
installed. If this option is installed on your console, there will be a BNC
coaxial connector protruding from one of the three option slots on the back
panel of the console.
?? Proper cabling for the Remote Video system. Because it uses an
Ethernet-based communication scheme, there are specific rules for the cabling
of the ColorNet Remote Video system. See the following topic, System Wiring.
?? “T”-connectors or Drop Cables for connecting to Encore Remote
Video Nodes and to the Encore console, depending on which cabling method
you are using.
?? An Encore Node for each Remote Video location. Encore nodes are
available in portable versions, and in permanent Wall-Mount versions that fit
inside a standard 3½ inch deep, four-gang electrical back box. Portable Encore
Nodes come with a separate power supply.
?? A color VGA monitor for each location, equipped with a standard
high-density 15-pin “D” connector.
You will also need an AC power outlet at your Remote Video location to plug
in the monitor and the power supply for the Encore Node. A complete listing
of ColorNet Remote Video products is shown in the following table:
Part No. Product
7-1030
Encore 24/48 with ColorNet Support Option
7-1040 Encore 48/96 with ColorNet Support Option
7-1050 Encore XL with ColorNet Support Option
7-1081 Encore XL/2 (comes with ColorNet Support standard)
7-1090 Encore 24/48 Expanded with ColorNet Support Option
7-1110 Encore 48/96 Expanded with ColorNet Support Option
7-2141 Encore Remote Video Kit (includes VGA Monitor, Encore Node, & Power Supply)
7-3021 ColorNet Drop Cable, 6’ length
7-3022 ColorNet Drop Cable, 12’ length
7-3023 ColorNet Drop Cable, 25’ length
7-3024 ColorNet Drop Cable, 50’ length
7-3025 ColorNet Drop Cable, 100’ length
7-4031 Single Gang Network Wall Plate (ColorNet Tap)
7-9021 ColorNet Tap Assembly (without Wall Plate)
7-9022
ColorNet 50? Terminator, Grounded
7-9022
ColorNet 50? Terminator, Ungrounded
7-3202 RG 58 /U Coaxial Cable with BNC connectors, 25’ length
7-3203 RG 58 /U Coaxial Cable with BNC connectors, 50’ length
7-3204 RG 58 /U Coaxial Cable with BNC connectors, 100’ length
7-3205 RG 58 /U Coaxial Cable with BNC connectors, 200’ length
7-3200 RG 58 /U Coaxial Cable with BNC connectors (specify length when ordering)
7-9011 BNC “T” Connector
