Sensor (ADF 2nd scan) static jam service check
Action Yes No
Step 1
Make sure that the paper is loaded properly. Use the
recommended paper.
Does the problem remain?
Go to step 2. The problem is
solved.
Step 2
Restart the printer.
Does the problem remain?
Go to step 3. The problem is
solved.
Step 3
Check the sensor (ADF 2nd scan) paper path area for debris and
obstructions.
Is the sensor free of debris and obstructions?
Go to step 5. Go to step 4.
Step 4
Remove obstructions along the sensor paper path.
Does the problem remain?
Go to step 5. The problem is
solved.
Step 5
a Enter the Diagnostics menu, and then navigate to:
Scanner diagnostics > Sensor tests
b Find the sensor (ADF 2nd scan).
Does the sensor status change while toggling the sensor?
Contact the next
level of support.
Go to step 6.
Step 6
a Reseat the sensor cable from the ADF controller board.
b Check the sensor and its actuator for improper installation and
damage.
Is the sensor properly installed and free of damage?
Contact the next
level of support.
Go to step 7.
Step 7
Reinstall the sensor.
Does the problem remain?
Contact the next
level of support.
The problem is
solved.
7018
Diagnostics and troubleshooting
109
