Lexmark XM3250 - Front Removals; Nameplate Removal; MPF with Front Access Cover Removal

Front removals
Nameplate removal
1 Open the front door.
2 Push the latch to the left, and then remove the screw (A).
3 Remove the four screws (B).
4 Remove the nameplate.
Note: The MPF hinders the removal.
Warning—Potential Damage: Avoid damaging the cable (C) when removing the nameplate.
MPF with front access cover removal
1 Remove the nameplate. See “Nameplate removal” on page 252.
2 Remove the right cover. See “Right cover removal” on page 237.
7018
Parts removal
252
