Lexmark XM3250 - Top Access Cover Removal

6 Push the MPF with front access cover to the right, and then remove it.
Top access cover removal
1 Remove the nameplate. See “Nameplate removal” on page 252.
2 Remove the three screws (A), and then remove the cover (B).
A A
B
7018
Parts removal
254
