Main drive
1 MPF
2 Paper input
3 Main drive gearbox motor
4 Transfer roller
5 Photoconductor
6 Fuser
7 Paper exit
8 Duplex
The gearbox provides mechanical power to the printer. Its motor transfer power through a number of gears to
the following parts: MPF, paper input, transfer roll, photoconductor drum, fuser, paper exit, and duplex.
7018
Theory of operation
449
